OBD GPS Tracker with Built In Vehicle Diagnostics
SnapTrack OBD Pro 4G GPS Tracker
SnapTrack OBD Pro – Plug-and-Play 4G GPS Tracker with Advanced Vehicle Diagnostics
The SnapTrack OBD pro is a compact and powerful 4G LTE GPS tracker designed for effortless installation and comprehensive vehicle monitoring. Ideal for fleet management, usage-based insurance, and personal vehicle tracking, this device plugs directly into your vehicle's OBDII port, providing real-time location data and in-depth diagnostics.
Equipped with advanced features such as driving behaviour analysis, fault code detection, and multiple alert notifications, the SnapTrack OBD pro ensures you stay informed about your vehicle's performance and safety. Its dual GPS and BeiDou positioning systems guarantee accurate tracking, while the 4G connectivity ensures reliable data transmission.
Ideal For:
-
Fleet management
-
Usage-based insurance programs
-
Personal vehicle monitoring and diagnostics
-
Car rental and rideshare vehicle tracking
Enhance your vehicle’s intelligence with the SnapTrack OBD—where plug-and-play convenience meets powerful tracking and diagnostics.
Couldn't load pickup availability
Pickup available at unit 1/8 Merino Street
Usually ready in 24 hoursPairs well with
In stock! Ships within 1-2 business days.
First Year Subscription Free
1-Year Limited Warranty
Complimentary Standard Shipping
SnapTrack OBD Pro 4G GPS Tracker
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
Use this text to answer questions in as much detail as possible for your customers.
-
Customer Support
Use this text to answer questions in as much detail as possible for your customers.
-
FAQ’s
Use this text to answer questions in as much detail as possible for your customers.
-
Contact Us
Use this text to answer questions in as much detail as possible for your customers.
- Simply plug into the OBDII port—no tools or professional assistance required.
- Monitor your vehicle's location with precision using GPS and BeiDou satellite systems.
- Access vital vehicle data, accurate mileage, fault code, ACC status, fuel consumption statistics, battery voltage, engine speed, etc.
- Detect and receive alerts for harsh acceleration, braking, cornering, and collisions to promote safer driving habits.
- Stay informed with instant notifications for overspeeding, ignition status changes, geo-fence breaches, and device removal.
- Ensure consistent data transmission with 4G networks
- Small and unobtrusive, the device seamlessly integrates into your vehicle's interior.
Product Specifications
Positioning & Location
Positioning system GPS, GLONASS, BDS, GALILEO, AGPS, LBS
Accuracy <2.5m CEP
Track sensitivity -165dBm
Acquisition sensitivity –148 dBm (cold); –156 dBm (hot)
TTFF (open sky) Avg. Hot start <2s - Avg. Cold start <38s
Cellular
Communication network - 4G Cat 1, 2G (GSM)
Frequency
VL502 (L):
LTE-FDD: B2/B3/B4/B5/B7/B8/B28/B66
GSM: B2/B3/B5/B8
VL502 (E):
LTE-FDD: B1/B3/B5/B7/B8/B20/B28
GSM: B2/B3/B5/B8
VL502 (A):
Cat M1: B2/B4/B5/B12/B13
Cat NB2: B2/B4/B5/B12/B13
Power
Battery 50mAh/3.7V
Solar power 9–33VDC
Power consumption Standby: ≤ 5mA
Interface
LED indication Status (Blue)
SIM Nano-SIM
Digital I/Os N/A
Analog I/Os N/A
Voltage detection 0–33V (±0.3V)
Memory capacity 1000 GPS data entries
USB Micro USB
GNSS antenna Internal
Bluetooth antenna Internal
Serial ports N/A
Physical Specs
Dimensions 61.0 x 52.0 x 26.0mm
Weight 55g
Operating environment
Operating temperature -20℃ to 70℃
Operating humidity 5%～95%, non-condensing
IP rating N/A
OBD Port
Connection OBDII port
Data K-Line, CAN Bus
OBD protocols
ISO 9141-2 (5 baud init, 10.4 kbaud)ISO 14230-4 KWP (5 baud init, 10.4 kbaud)ISO 14230-4 KWP (fast init, 10.4 kbaud)ISO 15765-4 CAN (11 bit ID, 250 kbaud)ISO 15765-4 CAN (11 bit ID, 500 kbaud)ISO 15765-4 CAN (29 bit ID, 250 kbaud)ISO 15765-4 CAN (29 bit ID, 500 kbaud)SAE J1939 CAN(29 bit ID, 250 kbaud)SAE J1939 CAN(29 bit ID, 500 kbaud)
Features
Voice monitoring range N/A
Sensors Accelerometer
Scenarios Car Fault, Over-Speed, Ignition detection, Collision, Geo-fence entry/exit, Power on, Device pull-out, Engine idling
Driving behavior analysis (DBA) Harsh acceleration, Harsh braking, Harsh cornering, Collision
Bluetooth BLE 4.2
Configuration support SMS, Allied Track, PC Tools
Certification FCC, CE, RoHS
Included in the box
Charging Cable
Sim Card
Plug-In Telematics: Smart Diagnostics & Tracking
First Year Subsciption Free
Get your first year's subscription free when you purchase one of our gps trackers. Get tracking as soon as you take our trackers out of the box.
FAQs
Please read our FAQs page to find out more.
Do I need a subscription to use my GPS tracker?
Yes. All Allied Track devices require an active subscription to enable real-time tracking, alerts, and data access. Your subscription includes access to our platform, a SIM card, and mobile data—so there's nothing extra to purchase.
Which app or platform do I use to track my device?
Vehicle, OBD, and asset trackers use the Allied Track app, available on desktop and on iOS & Android mobile devices.
Pet and personal trackers connect through a dedicated app tailored for advanced safety tracking. App download links and setup instructions are included with your product.
How accurate is the GPS tracking?
Allied Track GPS trackers offer location accuracy of up to 2.5 metres under optimal conditions. Advanced models may use dual-frequency GNSS and assistive positioning to maintain precision in built-up or low-signal areas.
Can I manage multiple trackers on one account?
Yes. You can manage the subscriptions of multiple trackers of the same type from a single Allied Track account. Whether you're monitoring a fleet of vehicles or several pet trackers, your dashboard allows easy monitoring and control.
What happens if the tracker is disconnected or loses signal?
Most Allied Track devices include a backup battery and local storage. If signal or power is lost, the device will store data and sync automatically once reconnected. Alerts for disconnection, tampering, low battery, and more are available depending on the model.
